Quick view
County of origin
Ukraine
Crew
2+6/2+8
Acceleration
0-60 km/h not more than 35 sec, 0-100 km/h not more than 55 sec
Air Conditioning
12 kW Cooling/Heating capacity
Alternator
260 A
Altitude Operation
Capable of operations at altitudes over 5000 m
Ambient Temperature Range
From -40°C to + 55°C (without preparation)
Auxiliary Batteries
24 V
Brakes / ABS
Knorr-Bremse;Pneumatic system equipped with ABS;Rear parking brake
Braking Distance
60-0 km/h — 25 m, 100-0 km/h — 40 m
Central Tire Inflation System (CTIS)
Pre-programmed rapid selection on the dashboard with variable payload and terrain settings:, Terrain Setting 1: Highway, Terrain Setting 2: Cross-country, Terrain Setting 3: Mud, Sand, Snow, Terrain Setting 4: Emergency, Payload Setting 1: Curb Weight, Payload Setting 2: Half Load, Payload Setting 3: Gross Weight
Combat module
Manual or automatic (optional)
Configuration
Left-hand drive
Construction
Monocoque hull
Cooling System
Custom Solution, Viscous fan clutch driven by the crankshaft, Transmission, differential, and transfer case cooling integrated into the power unit
Crew and troop seats
Mine-resistant with 4-point seat belts
Crew Compartment Ballistic Protection
PZSA-6
Curb Weight
14,200 kg
Differential and Hub Type
Axeltech 4000 series with air intake system
Differential Lock
Longitudinal, rear, front
Driver Video Surveillance System
1 X Rear view camera with protection (roof mounted, effective in low light). Images are sent to the driver's dashboard, 1 X Front view camera with protection (roof mounted, effective in low light). Images are sent to the driver's dashboard
Electrical System
24 V
Engine
Cummins 8.9L ISLe (6ISLe450 31) 450 hp, 335 kW, 6-cylinder turbo-diesel
Engine Compartment Ballistic Protection
PZSA-6
Entry/Exit
1 x hydraulically operated rear ramp with emergency hatch + explosive locks, 2 x Crew hatches, 2 x landing hatches
External Power Socket
24 V NATO power sockets at the front and rear of the vehicle
Fire Suppression System
Crew Cabin: Charged with fluoroketone, Engine Compartment: Powder, Wheels: Powder
Front Lights
2 x High beam headlamps, 2 x Low beam headlamps, 2 x Daytime running lights, 2 x Side lights, 2 x Fog lights, 2 x BLACKOUT lights
Fuel Capacity
250L tank, diesel fuel
Fuel Tank Capacity
250 liters
Interior Lighting
2x LED white (Driver and co-driver), 6x LED white (Crew)
Internal Outlets
24 V, 12 V, 5 V
Main Batteries
24 V
Mine Protection (Engine and Crew Compartments)
STANAG-4569 level 3a+4b with potential to upgrade to 4a+4b
Operational Range
Highway — 1,000 km, Off-road — 500 km
Parking Brakes
20° Gradient
Payload
2,200 kg
Rear Lights
2 x Reversing lights, 2 x Rear stop lights, 1 x Additional stop light (top), 2 x Side lights, 1 x Additional light (rear), 2x BLACKOUT rear stop lights, 2x BLACKOUT side lights
Rear Ramp
Hydraulic rear ramp with adjustable opening/closing speed
Seating
Adjustable driver and co-driver seats, 6-8 rear seats facing inward
Service Brakes
30° Gradient
Steering
Hydraulic power steering
Suspension
Hydropneumatic independent suspension, Wheel travel – 300 mm, Light and compact A-type control arms, Robust construction, Upper and lower control arms, 4 hydropneumatic nitrogen-charged struts with integrated shock absorbers
System Voltage
24 V
Tires
16.00R20
Transfer Case
ZF VG750 permanent all-wheel drive, 2-speed, Transfer case lock, Towing capability, High-range ratio 2:1, Low-range ratio 1:1
Transmission
Allison 3200SP 6-speed automatic
Travel Speed
Highway — 100 km/h, Off-road — 60 km/h
Turning Circle
< 16 m (not more than 8 m)
Turning Radius
not more than 8 m
Wheelbase
3300 mm
Wheels
Tires: Michelin 16.00 R20 XZL, All-terrain tread, Rim: Split rims, Total: 4 units
Quick view
County of origin
Ukraine
Armor and mine protection
PZSA-5 all-round ballistic protection, STANAG 4569 level 1 mine protection
Bullets
6x on the sides / 2x at the back
Crew
7+1
Engine type
4.5L V8 - turbodiesel / 1VD-FTV (EGR)
Kernmanuet
4,820 kg
Number of doors
4x side/rear, single-leaf
Power
295 hp
Seat configuration
2x - in the cabin, 2x - behind the folding cabin seats, 4x - in the crew cabin
Wheel arrangement
4x4
Quick view
County of origin
Ukraine
Crew
3+6
Power
300 hp
Enlarged interior
Improved interior, optimized internal layout, improved ergonomics and increased efficiency of infantry boarding and disembarking
Increased level of protection
Level 2 and above
Open architecture
A universal solution for integrating weapons systems, passive and active defense, communications and other military technologies
Platform compatibility
Most spare parts and components are compatible with the BMP-1 and BMP-2 platforms, primarily in chassis units and transmission mechanisms
Simplified control
Semi-automatic transmission and reduced driver workload
Speed
65 km/h
